ConXport Polarizing Microscope

Optical System

UCIS infinity corrected optical system

Body

Anti-microbial treated body having the feature of transmission and reflection mode polarization microscopy with built in filter holders.

Viewing Head

30 degree inclined fixed Trinocular Head (3 way beam splitter) with IPD 52mm-75mm

Magnification

40X-1000X

Eyepiece

A pair of WF 10X/22mm FOV. Eye point height adjustment up to 21mm with locking screw and cross hair graticule.

Objective

Plan Achromatic polarizing objectives of

X POL N.A. 0.13 W.D. 17.0mm

10X POL N.A. 0.3 W.D. 10.0mm

20X POL N.A. 0.5 W.D. 2.1mm

40X POL N.A. 0.75 W.D.1.1mm

100X

Condenser

Strain free focusable swing out polarizing condenser with magnification labeling, color making and Add on lens.

Mechanical Stage

Centrable polarization 360 degree rotating circular stage of diameter 178mm with graduation of 1micrometer and adjustable brake and venire. Object guide mechanical stage for XY movement of the specimen with knob and stage clips.

Focusing Control

Co-axial coarse and fine focusing control with large knobs and torque adjustment feature. Coarse focusing stroke of 22mm and fine focusing stroke of 100 micrometer.
